Private WireGuard VPN with selective Tor routing

I use WireGuard to join my servers, laptop, and phone into one private network. Laptop and phone traffic goes through Tor. Server-to-server traffic stays normal.

# The WireGuard server (Ubuntu)

This server is the WireGuard endpoint. Clients connect to it. It routes traffic.

# System optimization (sysctl)

First, tune the server network settings. Many of these settings are from my previous article about VPNs (here); add the following to /etc/sysctl.conf:

net.core.default_qdisc=fq
net.ipv4.tcp_congestion_control=hybla
fs.file-max=51200
net.core.netdev_max_backlog=250000
net.core.rmem_max=67108864
net.core.somaxconn=4096
net.core.wmem_max=67108864
net.ipv4.ip_forward=1
net.ipv4.ip_local_port_range=10000 65000
net.ipv4.tcp_fastopen=3
net.ipv4.tcp_fin_timeout=30
net.ipv4.tcp_keepalive_time=1200
net.ipv4.tcp_max_syn_backlog=8192
net.ipv4.tcp_max_tw_buckets=5000
net.ipv4.tcp_mem=25600 51200 102400
net.ipv4.tcp_mtu_probing=1
net.ipv4.tcp_rmem=4096 87380 67108864
net.ipv4.tcp_syncookies=1
net.ipv4.tcp_tw_reuse=1
net.ipv4.tcp_wmem=4096 65536 67108864

At a minimum, net.ipv4.ip_forward=1 is required to allow the server to route traffic. The other settings are performance optimizations. I apply them with sudo sysctl -p.

# WireGuard installation

sudo apt install wireguard wireguard-tools
mkdir -p /etc/wireguard/ && cd /etc/wireguard/
wg genkey | tee server-privatekey | wg pubkey > server-publickey

Now, create the server’s configuration file at /etc/wireguard/wg0.conf:

[Interface]
Address = 192.168.42.1/24
ListenPort = 51820
PrivateKey = <paste content of server-privatekey here>

Start the WireGuard service and enable it to launch on boot sudo systemctl start wg-quick@wg0 && sudo systemctl enable wg-quick@wg0.

I check its status with sudo journalctl -eu wg-quick@wg0.service.

# Generating peer configurations

With the server running, I generate keys for clients and add them as peers:

wg genkey | tee client1-privatekey | wg pubkey > client1-publickey
wg genkey | tee raspberrypi-privatekey | wg pubkey > raspberrypi-publickey
wg genkey | tee myphone-privatekey | wg pubkey > myphone-publickey
wg genkey | tee mypc-privatekey | wg pubkey > mypc-publickey

# Integrating Tor and firewall rules

Previous-previous version with local TOR daemon

My Tor installation was already described here. The crucial step is to ensure Tor’s listeners are bound to the WireGuard interface IP, /etc/tor/torrc:

AutomapHostsOnResolve 1
AutomapHostsSuffixes .onion,.exit
AvoidDiskWrites 1
DNSPort 192.168.42.1:9053
TransPort 192.168.42.1:9040

Previous version with TOR daemon in docker

mkdir -p /opt/tor/data
chown -R 100:101 /opt/tor/data
mkdir -p /etc/tor
cat > /etc/tor/torrc << 'EOF'
AutomapHostsOnResolve 1
AutomapHostsSuffixes .onion,.exit
AvoidDiskWrites 1
DNSPort 192.168.42.1:9053
TransPort 192.168.42.1:9040
DataDirectory /var/lib/tor
EOF

docker run -d --name tor \
  --restart unless-stopped \
  --network host \
  -v /etc/tor/torrc:/etc/tor/torrc:ro \
  -v /opt/tor/data:/var/lib/tor \
  docker.io/dockurr/tor:0.4.8.21

docker logs tor -f
...
...
...
Nov 17 18:04:07.000 [notice] Bootstrapped 100% (done): Done

This time I set up Tor in podman and route traffic through it.

mkdir -p /opt/tor/data
chown -R 100:101 /opt/tor/data
mkdir -p /etc/tor
cat > /etc/tor/torrc << 'EOF'
AutomapHostsOnResolve 1
AutomapHostsSuffixes .onion,.exit
AvoidDiskWrites 1
DNSPort 192.168.42.1:9053
TransPort 192.168.42.1:9040
DataDirectory /var/lib/tor
EOF

mkdir -p /etc/containers/systemd

cat > /etc/containers/systemd/tor.container << 'EOF'
[Unit]
Description=Tor (dockurr/tor) via Podman Quadlet
Wants=network-online.target
After=network-online.target

[Container]
Image=docker.io/dockurr/tor:0.4.8.21
Network=host

Volume=/etc/tor/torrc:/etc/tor/torrc:ro
Volume=/opt/tor/data:/var/lib/tor:Z

ContainerName=tor

[Service]
Restart=always
RestartSec=2

[Install]
WantedBy=multi-user.target
EOF

systemctl daemon-reload
systemctl start tor.service
systemctl enable tor.service

journalctl -u tor.service -f
...
...
...
Nov 17 18:04:07.000 [notice] Bootstrapped 100% (done): Done

Security Note: Nobody audits this for me. I checked exact docker.io/dockurr/tor:0.4.8.21; responsibility stays mine.

The noticeable part here is --network host. Routing matches the local daemon case. Now I update /etc/wireguard/wg0.conf with iptables rules to route client traffic to Tor and lock down the server:

[Interface]
Address = 192.168.42.1/24
ListenPort = 51820
PrivateKey = <paste content of server-privatekey here>

PostUp = iptables -t nat -A PREROUTING -i %i -p tcp --syn -j REDIRECT --to-ports 9040
PostUp = iptables -t nat -A PREROUTING -i %i -p udp --dport 53 -j REDIRECT --to-ports 9053
PostUp = iptables -A INPUT -i %i -p tcp --dport 9040 -j ACCEPT
PostUp = iptables -A INPUT -i %i -p udp --dport 9053 -j ACCEPT
PostUp = iptables -A FORWARD -m conntrack --ctstate RELATED,ESTABLISHED -j ACCEPT
PostUp = iptables -A FORWARD -i %i -p udp -j DROP
PostUp = iptables -t nat -A POSTROUTING -o ens3 -j MASQUERADE

PostDown = iptables -t nat -D POSTROUTING -o ens3 -j MASQUERADE
PostDown = iptables -D FORWARD -i %i -p udp -j DROP
PostDown = iptables -D FORWARD -m conntrack --ctstate RELATED,ESTABLISHED -j ACCEPT
PostDown = iptables -D INPUT -i %i -p udp --dport 9053 -j ACCEPT
PostDown = iptables -D INPUT -i %i -p tcp --dport 9040 -j ACCEPT
PostDown = iptables -t nat -D PREROUTING -i %i -p udp --dport 53 -j REDIRECT --to-ports 9053
PostDown = iptables -t nat -D PREROUTING -i %i -p tcp --syn -j REDIRECT --to-ports 9040

[Peer]
PublicKey = <paste content of client1-publickey>
AllowedIPs = 192.168.42.2/32

[Peer]
PublicKey = <paste content of raspberrypi-publickey>
AllowedIPs = 192.168.42.3/32

[Peer]
PublicKey = <paste content of myphone-publickey>
AllowedIPs = 192.168.42.4/32

[Peer]
PublicKey = <paste content of mypc-publickey>
AllowedIPs = 192.168.42.5/32

Note: Replace ens3 with the server’s public-facing network interface (e.g., eth0).

Finally, apply all the changes by restarting the services sudo systemctl restart tor && sudo systemctl restart wg-quick@wg0.

# Client configs: split tunnel vs Tor full tunnel

# Client type A: split-tunnel (Ubuntu/Raspberry Pi)

These clients only use the VPN to access other devices on the 192.168.42.0/24 network. Their regular internet traffic will not go through the VPN.

Install WireGuard, sudo apt install wireguard wireguard-tools, create /etc/wireguard/wg0.conf:

[Interface]
PrivateKey = <paste private key for this specific client>
Address = 192.168.42.3/24

[Peer]
PublicKey = <paste content of server-publickey>
Endpoint = your.server.public.ip:51820
AllowedIPs = 192.168.42.0/24
PersistentKeepalive = 25

The AllowedIPs = 192.168.42.0/24 setting is the key here. It tells the client to only route traffic for the VPN subnet through the tunnel. PersistentKeepalive helps maintain the connection through NAT firewalls.

Don’t forget to start and enable the service: sudo systemctl start wg-quick@wg0 && sudo systemctl enable wg-quick@wg0.

# Client type B: full-tunnel over Tor (Windows/GrapheneOS)

These clients route all internet traffic through the VPN. The server then sends that traffic through Tor.

Create the configuration file and import it into the WireGuard app:

[Interface]
PrivateKey = <paste private key for mypc or myphone>
Address = 192.168.42.5/24
DNS = 192.168.42.1

[Peer]
PublicKey = <paste content of server-publickey>
Endpoint = your.server.public.ip:51820
AllowedIPs = 0.0.0.0/0

AllowedIPs = 0.0.0.0/0, this is the standard “full-tunnel” setting that directs all IPv4 traffic through the VPN. DNS = 192.168.42.1 is critical. It forces the client to use my server for all DNS requests, which are then resolved securely by Tor. This prevents “DNS leaks” where requests might bypass the VPN.

# Windows AllowedIPs note

While AllowedIPs = 0.0.0.0/0 is the most secure setting, some Windows users prefer AllowedIPs = 0.0.0.0/1, 128.0.0.0/1 to avoid certain issues with local network access. With this alternative, setting the DNS directive as shown above is absolutely essential to prevent DNS leaks.

# Verify VPN connectivity and Tor exit

I verify two things:

Check Internal VPN Connectivity, from one client (e.g., my PC at 192.168.42.5), ping another client (e.g., my phone at 192.168.42.4):
```
ping 192.168.42.4
PING 192.168.42.4 (192.168.42.4) 56(84) bytes of data.
64 bytes from 192.168.42.4: icmp_seq=1 ttl=64 time=40.6 ms
...
```
A successful reply means the private network is up.

Check Tor Routing on a Full-Tunnel Client, on my PC or phone, open a terminal or browser and check my public IP:

curl https://wtfismyip.com/json

The output should show an IP address belonging to a Tor exit node:

{
  "YourFuckingIPAddress": "185.34.33.2",
  "YourFuckingLocation": "France",
  "YourFuckingHostname": "tor.laquadrature.net",
  "YourFuckingISP": "Octopuce s.a.r.l.",
  "YourFuckingTorExit": true,
  "YourFuckingCity": "",
  "YourFuckingCountry": "France",
  "YourFuckingCountryCode": "FR"
}

If YourFuckingTorExit is true, the setup works.

Once private keys are transferred to their respective client devices, remove them from the server, rm -rf client1* mypc-* myphone-* raspberrypi-* server-*.
